Win Ground is a renewable energy that aims to create a sustainable and self-sufficient future. It offer state-of-the-art wind turbines and modular energy storage systems for homes and businesses to reduce reliance on the existing power grid. Win Ground also offers solutions that harness the limitless power of wind and solar energy. They can provide homeowners and business owners with reliable clean energy and increased energy independence.
| Item | Specifications | remark |
| 7.5kWh | ||
| Battery Type | LiFePO4 | |
| Typical Capacity (Ah) | 52Ah | |
| Typical Voltage (V) | 144V | |
| Connection | 1P45S | |
| Voltage Working Range (V) | 114.7V-159.7V | Single cell: |
| 2.55V-3.55V | ||
| Working Temperature(°C) | Charge: 0°C~+55°C, | |
| Discharge: -20°C~+55°C | ||
| Storage Temperature(°C) | -20°C~+35°C | |
| Nominal Capacity (kWh) | 7.488kWh | |
| Max. Charge Current(A) | 35A | |
| Max. Discharge Current(A) | 35A | |
| Cycle Life | >6000 | 25°C ,0.5C , |
| 90%DOD | ||
| Capacity retention | ≥95% | 25°C ,0.5C, |
| 500 cycle | ||
| SOC Accuracy | <8% | |
| Weight(kg) | ~80kg | |
| Dimensions(mm) | 606x220x730mm | L x W x H |
| IP Grade | IP65 | |
| Transportation SOC | 30% | |
| Cooling | Nature |
Cutting-edge technology: Win Ground products feature state-of-the-art technology, designed to maximise the efficiency of renewable energy systems.High-quality lithium batteries: Their energy storage systems use high-quality lithium batteries, providing long-term storage options.
Modular design: Win Ground products are modular, meaning they can be easily installed and scaled up as required.
Compatible with multiple renewable energy sources: Win Ground products are compatible with various renewable energy sources, ensuring flexibility and ease of integration.
Remote monitoring: Their systems can be monitored remotely, reducing maintenance costs, and ensuring optimal performance.
Win Ground's innovative range of renewable energy solutions offers a diverse range of applications. From residential properties and commercial buildings to industrial and healthcare facilities, Win Ground products are effective in providing energy storage, reducing reliance on grid energy, and enabling uninterrupted power supply during power outages.
